| VirtualRadar.Interface.Listener Namespace |
The namespace for all of the interfaces and objects associated with classes that can listen to sources of
aircraft data and translate them into objects that the rest of the program can use.
Classes| Class | Description | |
|---|---|---|
 | ExtractedBytes |
The object returned by message extractors that describes the bytes corresponding to one message.
|
| PolarPlot |
A DTO that carries a single point in a polar plot.
|
| PolarPlotSlice |
A DTO that carries a slice of polar plots for a given receiver.
|
| ReceiverFormatName |
Describes a registered receiver format.
|
Interfaces| Interface | Description | |
|---|---|---|
 | IAircraftListJsonMessageBytesExtractor |
The interface for objects that can extract AircraftListJson format messages.
|
| IAircraftListJsonMessageConverter |
The interface for an object that can turn an AircraftListJson into a collection
of BaseStationMessageEventArgs objects.
|
| IBeastMessageBytesExtractor |
The interface for objects that can extract the bytes of a Mode-S message from
bytes sent from a Mode-S Beast (http://www.modesbeast.com)
|
| ICompressedMessageBytesExtractor |
The interface for objects that can extract bytes for a message from a compressed feed.
|
| IFeed |
The interface that ties together an aircraft list, which tracks the state of aircraft picked up by a
receiver or merged feed, and a receiver or merged feed's identifier from the configuration details.
|
| IFeedManager |
The interface for objects that can collect together a IFeed for each receiver and merged feed configured in settings.
|
| IListener |
The interface for objects that can listen to a stream of bytes and decode them into messages.
|
| IMergedFeedComponentListener |
The listener for a receiver that will be merged into a single feed by IMergedFeedListener.
|
| IMergedFeedListener |
A listener that merges together messages picked up by two or more listeners.
|
| IMessageBytesExtractor |
The interface for objects that can extract raw message bytes from an array of bytes.
|
| IPlaneFinderMessageBytesExtractor |
The interface for classes that can extract messages from Plane Finder feeds.
|
| IPolarPlotter |
The interface for objects that can track the values required for a polar plot.
|
| IPort30003MessageBytesExtractor |
The interface for objects that can extract Kinetic Port 30003 format messages.
|
| IReceiverFormatManager |
Manages the feed formats that the program can decode.
|
| IReceiverFormatProvider |
The interface that all receiver format providers must implement.
|
| ISbs3MessageBytesExtractor |
The interface for objects that can extract Mode-S messages from bytes read from an SBS-3.
|
Enumerations| Enumeration | Description | |
|---|---|---|
 | ExtractedBytesFormat |
An enumeration of the different formats that the payload of ExtractedBytes can be in.
|
Remarks
